Aluminium Gazebo 490 - Adjustable Posts, Polycarbonate Roof

Aluminium Gazebo 490 - Adjustable Posts, Polycarbonate Roof
1
2
3
4
5
6
7
Pictures 1, 2 and 3 show the 10'x16' gazebo. Picture 4 shows the 10'x10' gazebo. Pictures 5 and 6 show close up views.

Summary:

This low maintenance aluminium gazebo is available in two sizes, approximately 10'x10' or 10'x16' (3.1x2.9m and 3.1x5.0m) overall. The internal height to the underside of the eaves beam is a generous 6'3" (1.9m). Standard features include a strong and durable powder coated aluminium frame with a tinted twinwall polycarbonate roof canopy. The 10'x10' gazebo includes 4 corner posts. The larger 10'x16' gazebo includes 6 posts. The posts can be set in from the eaves beam if required to avoid an obstruction. Base plates with pre-drilled holes are included to ensure easy fixing into any hard surface. Polycarbonate is increasingly popular as a gazebo roof due to the combination of durability, good light transmission and reduced glare. It is stronger than a canvas canopy and provides good protection for garden furniture. This versatile gazebo is also suitable as a hot tub cover or a smoking shelter. Instructions are supplied for DIY self assembly.

Back to the Top
  • Powder coated aluminium frame
  • Virtually no maintenance required
  • Extruded hollow section box profile profile framing throughout with concealed full length stiffeners to provide extra strength and rigidity
  • Extruded 60mm x 60mm box profile aluminium posts with rounded corners
  • Extruded 70mm x 60mm box profile aluminium eaves beam
  • Extruded 60mm x 40mm box profile aluminium glazing bars
  • Extruded structural aluminium gutter
  • Aluminium posts approximately 6'3" long (1900mm)
  • Tinted 6mm thick twinwall polycarbonate roof
  • Glazing bars at approximately 28" centres (725mm)
  • Integral glazing system holds the polycarbonate glazing in position securely
  • The unique glazing bar design retains the polycarbonate panels with continuous vertical grooves to each side
  • Moulded gutter stop end outlets included, with downpipe connectors suitable for rigid pipes or flexible hoses
  • Moulded glazing bar end plates included
  • Pre-drilled base plates ensure easy fixing into any hard surface including concrete, paving or decking
  • All components required for assembly are supplied cut to length and pre-drilled
  • Overall external height approximately 6'9" (2050mm)
  • Internal height to underside of glazing bars approximately 6'3" (1900mm)
  • Adjustable post positions - the design allows the posts to be set in from the eaves beam if required to avoid an obstruction
  • Maximum available internal width between the posts in the front 10' (3.1m) wide wall approximately 9'1" (2.78m)
  • If you cut the posts to reduce the height you may need to drill new holes in order to attach the base plates.
  • In normal circumstances we do not advise cutting the posts by more than 150mm (6"), which reduces the clearance below the eaves beam to around 1750mm (5'9").

10' x 10' gazebo (3.1m x 2.9m)

  • Overall external roof size 10'3" wide x 9'7" long (3.13m x 2.91m)
  • Base size with standard post positions 9'6" wide x 4'9" long (2.90m x 1.46m)
  • Fixed internal width between the posts in the 9'7" long side wall approximately 4'5" (1.34m)
  • 4 aluminium posts included
  • 3 triangular powder coated steel eaves braces per post to ensure stability

10' x 16' gazebo (3.1m x 5.0m)

  • Overall external roof size 10'3" wide x 16'6" long (3.13m x 5.02m)
  • Base size with standard post positions 9'6" wide x 11'9" long (2.90m x 3.57m)
  • Fixed internal width between the posts in the 16'6" long side wall approximately 5'6" (1.69m)
  • 6 aluminium posts included
  • 3 triangular powder coated steel eaves braces per corner post to ensure stability
  • 2 triangular powder coated steel eaves braces per intermediate post to ensure stability

POWDER COATED ALUMINIUM: Extruded hollow section aluminium profiles are cut to size and drilled or welded to form a lightweight and strong frame. Aluminium is ideal for outside use because it does not corrode like steel. The aluminium is powder coated, a tough paint finish which has excellent weathering properties.

TWIN WALL POLYCARBONATE: Twin wall polycarbonate is virtually unbreakable and very practical. Polycarbonate is safe with small children or pets around and easy to handle during installation. Tinted polycarbonate reduces glare by diffusing light in the same way as sunglasses.

SIZES - WIDTH AND LENGTH: The sizes are listed alongside the price. The first dimension listed is the width and the second dimension is the length. The roof sheets and glazing bars run across the width of the building. The sizes listed are the overall roof sizes.
